Ecobud

A Revolutionary Low powered zero maintenance system for treatment of sewage and commercial effluents.

Salient Features of EcoBud STP

• STP shall be compact, have minimum Moving Parts, Consume Very Low Power and be odor free.
• The first stage of treatment provides for recovery of biogas while removing over 30-40% of the BOD/COD. The equalization tank shall be utilized for the same obviating the need for a separate tank.
• Second Stage consists of a Submerged Aerobic Fixed Film (SAFF) Bioreactor, which allows for a very high MLSS (High Microbial loading rate in a compact space).
• Also, a natural draft aeration system (Venturi aeration) provides the necessary aeration for the microbial consortia in the fixed film bioreactor.
• The honeycomb structure of the SAFF Bioreactor provides longer paths for the air bubbles to travel allowing for a very high oxygen transfer between the sewage and the microbial biofilm.
• This is the unique feature of the Eco-Bud system which enables a very high rate of biodegradation of organic pollutants in the sewage.
• Another 45-50% of the organic loads are removed in this stage reducing the power requirement by 30-40%.
• A turbine blower-based aeration system is provided in the next MBBR stage to remove the remaining organic loads.
• The blower is a low power consuming, high efficiency equipment, and the aeration grid is a non-clog type system.
• Collection cum equalization tank is used as anaerobic digester as well to reduce power requirement and recover biogas and constructed of RCC is placed below the ground level.
• All other tanks of STP in RCC can be built below the ground as required
• A metered dosing system is provided to have better control on dosing rate and to avoid the wastage of chemical.
